Drone Frames
Buy Drone Frames in India for Agriculture, Industrial & Commercial UAVs.
Bharat Skytech offers a wide range of drone frames in India for agriculture, industrial, commercial, and custom UAV applications. Our drone frames include 10L, 16L, 20L and heavy-duty platforms, with 4-axis quadcopter and 6-axis hexacopter configurations from trusted brands such as EFT.
Whether you are building an agriculture spraying drone, industrial UAV, survey drone, or heavy-lift platform, you can choose a drone frame based on payload capacity, wheelbase, axis configuration, motor compatibility, battery voltage, and application requirements.
EFT E620P 20L Agricultural Drone Frame
EFT E616P 16L Agricultural Drone Frame
EFT G18 20L Agricultural Drone Frame
EFT E420P 20L 4 Axis Agricultural Drone Frame
EFT E416P 16L 4 Axis Agricultural Drone Frame
EFT E410P 10L 4 Axis Agricultural Drone Frame
EFT E610P 10L Agricultural Drone Frame
EFT G06 6L Agricultural Drone Frame
X950 Industrial Drone Frame
Our Drone Frames
A drone frame is the structural foundation of a UAV. It supports the motors, propellers, flight controller, battery, payload, landing gear, wiring, and other essential components. The right frame should be selected according to payload requirements, frame size, wheelbase, motor and propeller compatibility, battery voltage, flight controller, and the intended application.
Explore drone frames for different UAV applications, payload requirements, and configurations.
Our range includes agriculture drone frames, industrial drone frames, quadcopter frames, hexacopter frames, foldable drone frames, and heavy-duty UAV platforms.
Agriculture Drone Frames
Agriculture drone frames are designed to support spraying tanks, batteries, motors, pumps, flight controllers, landing gear, and other components used in agricultural UAVs.
Available configurations include 6L, 10L, 16L and 20L agriculture drone frames, depending on the model. The range includes EFT platforms such as E410P, E416P, E420P, E610P, E616P, E620P and G-series frames.
Industrial Drone Frames
Industrial UAV frames are designed for applications where the drone needs flexible payload mounting and integration options.
The EFT X950 Industrial Drone Frame, for example, has a 950 mm wheelbase, 23-inch propeller compatibility, IP54 protection, multiple payload mounting zones and a spacious flight-control bay for different controller configurations.
It can be configured for applications such as:
- Aerial surveying
- Inspection
- LiDAR integration
- Thermal imaging
- Infrastructure monitoring
- Industrial surveillance
- Agriculture mapping
- Custom UAV development
Types of Drone Frames
Choosing the right UAV frame starts with understanding the different frame configurations available.
Quadcopter Drone Frames
A quadcopter drone frame uses four arms and four motors. These frames can provide a relatively simple platform for lightweight and medium-duty UAV builds.
They are suitable for applications where the required payload and propulsion system can be supported by a four-motor configuration.
Bharat Skytech offers EFT 4-axis agriculture drone frames, including 10L, 16L and 20L configurations.
Hexacopter Drone Frames
A hexacopter frame uses six motors and six arms. This configuration is commonly used for heavier UAV platforms and agriculture spraying drones.
EFT’s E610P, E616P and E620P platforms are examples of 6-axis agriculture drone frames, with different wheelbases, propeller sizes, power systems and tank capacities.
Foldable Drone Frames
A foldable drone frame allows the arms or structural components to be folded for transportation and storage.
This can be particularly useful for agriculture drone operators, service providers and commercial UAV teams that regularly transport their drones between operating locations.
Heavy-Duty Drone Frames
Heavy-duty UAV frames are designed for larger propulsion systems and higher payload requirements.
The appropriate frame should always be selected together with compatible motors, ESCs, propellers, batteries and flight-control systems rather than based on frame size alone.
Drone Frame Sizes & Payload Configurations
Drone frames are available in different sizes depending on the intended application.
For agriculture drones, frame selection is commonly associated with tank capacity such as:
| Drone Frame Configuration | Typical Application |
|---|---|
| 6L Drone Frame | Compact agriculture spraying |
| 10L Drone Frame | Agriculture spraying and field operations |
| 16L Drone Frame | Medium/high-capacity spraying |
| 20L Drone Frame | Professional agriculture spraying |
| Industrial UAV Frame | Surveying, inspection, mapping and custom payloads |
For example, EFT’s E-Series includes 10L, 16L and 20L configurations with different wheelbases, propeller sizes and power requirements.
Important: Tank capacity is not the same as total drone payload or maximum take-off weight. The complete aircraft must be evaluated after considering the frame, motors, ESCs, propellers, battery, liquid payload and other equipment.
What Is a Drone Frame?
A drone frame is the main structural assembly of a UAV. It connects and supports the major components required to build a functioning drone.
Depending on the design, a drone frame can provide mounting locations for:
- Drone motors
- Propellers and propulsion systems
- Electronic speed controllers
- Flight controller
- GPS and navigation systems
- Battery
- Spray tank
- Pump and nozzles
- Cameras and sensors
- Landing gear
- Payload equipment
- Wiring and power distribution
The frame also affects the drone’s overall dimensions, wheelbase, component placement, weight distribution and available payload space.
How to Choose the Right Drone Frame
Selecting a drone frame should be based on the complete UAV configuration rather than frame dimensions alone.
1. Determine the Payload Requirement
First determine what the drone needs to carry.
For agriculture drones, this can include:
- Spray liquid
- Tank
- Pump
- Nozzles
- Battery
- Electronics
For industrial drones, the payload could include:
- LiDAR
- RGB camera
- Thermal camera
- Multispectral camera
- Inspection equipment
- Mapping sensors
- Communication equipment
2. Select the Right Frame Configuration
Decide whether your application requires a:
- Quadcopter frame
- Hexacopter frame
- Foldable drone frame
- Industrial UAV frame
- Heavy-duty drone frame
The configuration should match the required propulsion system and payload.
3. Check Wheelbase and Propeller Compatibility
The drone frame wheelbase must be compatible with the selected motors and propellers.
For example, EFT’s E-Series platforms use different wheelbases and propeller sizes according to their respective configurations.
4. Match the Motors and ESCs
The frame is only one part of the propulsion system.
Your selected motors, ESCs and propellers must be compatible with:
- Frame configuration
- Battery voltage
- Expected aircraft weight
- Required thrust
- Propeller diameter
- Operating conditions
For compatible propulsion components, explore our Drone Motors range.Â
5. Select the Correct Battery System
A larger drone frame may require a higher-voltage or higher-capacity battery depending on the complete propulsion configuration.
Bharat Skytech offers 6S–14S agriculture drone batteries, including high-capacity LiPo options from Evercell, Herewin and Tattu.
Explore our Agriculture Drone Batteries.
6. Check Flight Controller Compatibility
The flight controller should support the selected aircraft configuration and intended application.
For agriculture UAVs, flight-control systems can integrate functions such as GPS navigation, mission planning, terrain following and radar-based systems depending on the controller and configuration.
Explore Flight Controllers & Radars.
7. Consider Transportation and Storage
If your drone is regularly transported between farms, industrial sites or survey locations, a foldable drone frame can make transportation and deployment easier.
Agriculture Drone Frames for Spraying
Agriculture drone frames are specifically designed around the requirements of spraying UAVs.
A spraying drone frame must provide suitable mounting and structural support for:
- Spray tank
- Pump
- Nozzles
- Motors
- Propellers
- Battery
- Flight controller
- GPS
- Radar
- Landing gear
Bharat Skytech’s EFT range includes 6L, 10L, 16L and 20L agriculture drone frame configurations, depending on the model.
For example, the EFT E616P is available as a 16L 6-axis platform, while the E620P is a 20L 6-axis platform.
For operators building or repairing EFT platforms, we also stock EFT Drone Frame Parts, including frame arms, body components, PDBs, landing gear components and other replacement parts.
Industrial & Commercial Drone Frames
Not every UAV requires an agriculture spraying frame.
Industrial drone platforms can be configured for different payloads and missions.
The EFT X950, for example, is an industrial drone frame with a 950 mm wheelbase, 23-inch propeller compatibility, IP54 protection and four independent payload mounting zones. Its flight-control bay is designed to accommodate different controller systems and onboard equipment.
This type of industrial drone frame can be considered for:
Surveying and Mapping
A UAV frame can be configured with cameras, GPS/RTK equipment or other mapping payloads.
Infrastructure Inspection
Industrial UAV frames can support cameras and sensors used for inspection of infrastructure and industrial sites.
LiDAR Applications
A modular frame with suitable payload mounting can be configured around LiDAR equipment for aerial scanning and surveying.
Thermal Inspection
Thermal cameras can be integrated for applications such as equipment inspection and aerial monitoring, subject to the aircraft’s payload and power requirements.
Drone Frame Components You May Need
A complete UAV build normally requires much more than the frame itself.
Depending on the aircraft design, you may need:
Frame → Motors → ESCs → Propellers → Battery → Flight Controller → GPS → Remote Controller → Power Distribution → Payload → Wiring
Drone Motors
Motors provide the thrust required to lift the aircraft and its payload.
Explore our Hobbywing Drone Motors & Propellers for agriculture and UAV propulsion applications.Â
Drone Batteries
The battery must be selected according to the aircraft’s voltage, current requirements, weight and expected operating time.
Explore Drone Batteries for agriculture and UAV applications.Â
Flight Controllers & Navigation
A compatible flight controller manages the aircraft’s flight-control functions and interfaces with navigation and sensor systems.
EFT Frame Spare Parts
For maintenance and repairs, you can find compatible EFT Drone Frame Parts for multiple EFT platforms.Â
Drone Frame Components You May Need
Bharat Skytech supplies drone components for agriculture, industrial and UAV applications in India.
Genuine Drone Components: We supply products from established UAV component brands and provide product-specific specifications to help with component selection.
Multiple Frame Configurations: Our range includes different agriculture and industrial UAV platforms, including EFT 4-axis and 6-axis frames and the X950 industrial platform.
Complete Drone Components:Â A frame is only one part of a complete UAV build. Bharat Skytech also supplies motors, propellers, batteries, flight controllers, remote controllers, electrical components and other drone parts.
Technical Product Information: Product specifications such as wheelbase, tank capacity, propeller size, voltage and frame weight can help you compare different platforms before purchasing. EFT product pages provide these specifications for individual frame models.
GST Billing & Pan-India Supply: Bharat Skytech provides GST billing and supplies drone components to customers across India.
Compare Drone Frames Before Buying
When comparing drone frames, don’t compare only the price.
Consider:
| Factor | Why It Matters |
|---|---|
| Frame type | Determines aircraft configuration |
| Wheelbase | Affects propulsion and overall dimensions |
| Payload requirement | Determines required lifting capability |
| Tank capacity | Important for agriculture spraying |
| Propeller size | Must match motors and frame |
| Motor compatibility | Determines propulsion configuration |
| Battery voltage | Must match the complete power system |
| Frame weight | Contributes to total aircraft weight |
| Foldability | Useful for transportation |
| Payload mounting | Important for industrial UAVs |
| Waterproofing | Important for field applications |
| Spare-part availability | Helps with long-term maintenance |
Build Your Drone With the Right Components
Choosing the correct drone frame is the first step toward building a reliable UAV. The frame should be selected together with the propulsion system, battery, flight controller, payload and other components.
Whether you need an agriculture drone frame, 10L drone frame, 16L drone frame, 20L drone frame, quadcopter frame, hexacopter frame, foldable drone frame or industrial UAV frame, compare the technical specifications and select the platform that matches your actual aircraft requirements.
Explore Bharat Skytech’s range of drone frames and UAV components for agriculture, industrial and commercial applications across India.
Frequently Asked Questions
What is a drone frame?
A drone frame is the structural platform that holds the motors, electronics, battery, payload and other components of a UAV.
What are the different types of drone frames?
Common types include quadcopter frames, hexacopter frames, foldable drone frames, agriculture drone frames, industrial UAV frames and heavy-duty drone frames.
How do I choose a drone frame?
Choose the frame according to payload, aircraft configuration, wheelbase, motor and propeller compatibility, battery voltage, flight controller, dimensions and intended application.
What is an agriculture drone frame?
An agriculture drone frame is designed to support components used in agricultural UAVs, including spray tanks, pumps, motors, batteries, flight controllers and spray systems.
What is the difference between a quadcopter and hexacopter frame?
A quadcopter uses four motors, while a hexacopter uses six motors. The appropriate configuration depends on the aircraft’s payload, propulsion requirements, design and intended application.
What size drone frame do I need?
The required frame size depends on the complete aircraft configuration. For agriculture drones, tank capacity is one consideration, but total aircraft weight, propulsion system and battery must also be considered.
What is a foldable drone frame?
A foldable drone frame has arms or structural components that can be folded to make transportation and storage easier.
Which drone frame is suitable for a 10L agriculture drone?
The suitable frame depends on the complete propulsion and spraying configuration. Bharat Skytech offers EFT 10L configurations including the E410P and E610P.
Which drone frame is suitable for a 16L agriculture drone?
The EFT E616P is a 16L 6-axis agriculture drone frame, while the E416P provides a 16L 4-axis configuration.
Which drone frame is suitable for a 20L agriculture drone?
Bharat Skytech offers 20L configurations including the EFT E620P and E420P, with different aircraft configurations and specifications.
Can I buy EFT drone frame spare parts?
Yes. Bharat Skytech offers EFT frame components and spare parts for multiple EFT models, including E410P, E416P, E420P, E610P, E616P and E620P.
Where can I buy drone frames in India?
You can buy agriculture and industrial drone frames from Bharat Skytech, including EFT UAV platforms and related drone components.
